Fender American Performer Stratocaster HSS Black

• Alder body
• Two Yosemite single-coil Stratocaster pickups; Double Tap™ humbucking bridge pickup
• Push/Pull Pot for Coil Split on Bridge Pickup
• "Modern C"-shaped neck with 9.5"-radius fingerboard; 22 jumbo frets
• ClassicGear™ tuning machines; silver '70s logo

General

SERIES                                    American Performer

ORIENTATION                      Right-Hand

COLOR                                  Black

COUNTRY OF ORIGIN       US

Neck

NECK MATERIAL                 Maple

NECK FINISH                         Satin Urethane

NECK SHAPE                        Modern "C"

FINGERBOARD RADIUS     9.5" (241 mm)

FINGERBOARD                    Maple

POSITION INLAYS                Black Dot

NUMBER OF FRETS              22

FRET SIZE                                Jumbo

SCALE LENGTH                    25.5" (64.77 cm)

TRUSS ROD                           Standard

TRUSS ROD NUT                   1/8" American Series

STRING NUT                          Synthetic Bone

NUT WIDTH                           1.685" (42.8 mm)

NUT MATERIAL                     Synthetic Bone

Body

BODY                                     Alder

BODY FINISH                        Gloss Urethane

BODY SHAPE                       Stratocaster®

BODY MATERIAL                 Alder

Hardware

BRIDGE                                  6-Saddle Vintage-Style Synchronized Tremolo

PICKGUARD                         3-Ply Black

PICKUP COVERS                 Aged White

CONTROL KNOBS               Aged White Plastic

SWITCH TIP                           Aged White

HARDWARE FINISH             Nickel/Chrome

TUNING MACHINES           Fender® ClassicGear™

STRING TREES                       Dual-Wing

STRINGS                                Fender® USA 250L Nickel Plated Steel (.009-.042)

NECK PLATE                         4-Bolt

STRAP BUTTONS                   Vintage-Style

Electronics

BRIDGE PICKUP                   Double Tap™ Humbucking

MIDDLE PICKUP                  Yosemite® Single-Coil Stratocaster®

NECK PICKUP                      Yosemite® Single-Coil Stratocaster®

PICKUP CONFIG                 HSS

CONTROLS                           Master Volume, Tone 1. (Neck & Middle Pickup), Tone 2. Greasebucket™ Tone Circuit (Bridge Pickup)

SWITCHING                          5-Position Blade: Postion 1. Bridge Humbucking Pickup; Position 2. Middle Pickup and Bridge Humbucking Pickup; Position 3. Middle Pickup; Position 4. Neck and Middle Pickup; Position 5. Neck Pickup

SPECIAL ELECTRONICS     Push-Pull Pot On Tone 2 for Coil-Split
