Ibanez TOD10N-TKF, Tim Henson Signature, Black
BACK IN STOCK SOON
FREE UK delivery
Part-exchange welcome
Product Description
TOD10N As an artist, Tim Henson is always trying to update, invigorate and reinvent his band’s image. He has taken that same approach with the TOD10N, his signature nylon string electric guitar that is based on the Ibanez FRH model. The TOD’s most striking aesthetic feature may be the fingerboard inlay design, which Tim has dubbed as the “Tree of Death”. The name and the design are both nods to the iconic Ibanez “Tree of Life” inlay design, but with a twist.
Product Features
Nyatoh neck The Nyatoh neck provides a rich mid-low end. - Walnut fretboard A Walnut fretboard features a well-balanced tonal character from low to high end. - Solid Sitka Spruce top Solid Sitka Spruce top provides an enormous frequency range that offers wave after wave of shimmering highs along with tight mids and a full-bodied low end. - Sapele back and sides Sapele back and sides offer a full-bodied and warm mid-range and a bright tone. - Fishman® S-Core pickup The Fishman® S-Core pickup accurately translates a full guitar sound to whatever amplification system you plug into. - Ibanez AEQ210TF preamp w/Onboard tuner The AEQ210TF preamp provides the extra punch of on-board EQ, and the convenience of an easy-to-read digital tuner. - Walnut bridge The Walnut bridge transfers string vibration directly to the body, delivering a natural and warm tone.
Special Features
Modified FR hollow body w/ Fan bracing Its thin, compact body and superior high fret access contribute to the superb playability of this guitar. It has less feedback as there’s no sound hole on the body top. Fan bracing, which is commonly used for classical guitars, allows this guitar to have a warm and natural nylon string sound. - Side Sound Port The sound port on the body side allows you to feel and hear the pure acoustic tone of this guitar more clearly and directly. - 46mm width nut / 400mmR fretboard radius The combination of a narrow 46mm width nut and 400mmR fretboard radius offers easy fingering. - Tree of Death fingerboard inlay The name and the design of this fingerboard inlay are both nods to the iconic Ibanez “Tree of Life” inlay design, but with a twist.
Videos
https://youtu.be/Fch1tUtXc8I https://youtube.com/shorts/e92nJXj7GcE?feature=share
Specification
| Artist : | Tim Henson |
| Batteries Required : | 9V x1 |
| Body Back material (For Acoustic/Hollow) : | Sapele |
| Body Binding : | Pearloid binding |
| Body Depth@End : | 50 |
| Body Depth (For Hollow) : | 1.97 |
| Body Depth@Joint : | 50 |
| Body finish : | Satin Polyurethane |
| Body Length (For Hollow) : | 17.32 |
| Body length (mm) : | 440 |
| Body Shape (For Acoustic) : | FRH |
| Body Sides material (For Acoustic/Hollow) : | Sapele |
| Body thickness (mm) : | 50 |
| Body Top material (For Acoustic/Hollow) : | Solid Sitka Spruce |
| Body Width (For Hollow) : | 14.17 |
| Body Width (mm) : | 360 |
| Bracing : | Fan Bracing for FRH |
| Bridge : | Walnut |
| Color Name : | Transparent Black Flat |
| Controls, Pickup selector : | 1 Volume, Bass, Treble |
| Country of origin : | INDONESIA |
| EAN : | 4549763334558 |
| End width (mm) : | 58 at 14F |
| Fretboard : | Walnut |
| Fretboard Radius (inch) : | 15.75 |
| Fretboard Radius (mm) : | 400 |
| Inlay : | Tree of Death |
| Machine Head : | Gold Classical tuners |
| Neck finish : | Satin Polyurethane |
| Neck Joint : | Set-in |
| Neck Joint Position : | 16th fret joint |
| Neck Material : | Nyatoh |
| Neck thickness (1st fret, mm) : | 21 |
| Neck thickness (7th fret, mm) : | 22 |
| Neck Type : | C shape |
| Number of fret : | 22 |
| Number of Strings : | 6 |
| Nut : | Bone |
| Nut width (inch) : | 1.8 |
| Nut width (mm) : | 46 |
| Other item(s) included : | Hex wrench |
| Other Pickup : | Fishman® S-Core |
| Other Switches : | Tuner on/off switch, Phase on/off switch |
| Output Jack : | 1/4" output |
| Preamp (for Acoustic) : | Ibanez AEQ210TF preamp w/Onboard tuner |
| Recommended Bag : | IGB540-BK |
| Saddle material : | Bone |
| Scale (inch) : | 25.5 |
| Scale (mm) : | 648 |
| Series : | TOD-N |
| Special Strings : | D'Addario® XTC45 |
| String Gauges (from top to bottom) : | .028/.032/.040/.028W/.035W/.044W |
| String spacing (mm) : | 11.6 |
| Total length (mm) : | 990 |
| Tuning (from top to bottom) : | 1E,2B,3G,4D,5A,6E |
| Youtube_link_1 : | https://youtu.be/Fch1tUtXc8I |
| Youtube_link_2 : | https://youtube.com/shorts/e92nJXj7GcE?feature=share |
